Laadkabel 12/24V Brodit Molexbox - 6-pin 2.5A
Charging kit. The product is compatible with the holders that are equipped with the Easy-switching system, this means that it is possible to upgrade such a holder to have a fixed installation as power supply if desired. 12/24 Volt. The product is E-approved. Connect the power cable with a 2A fuse. 2,5A charger.
Discreet hard wire installation without visible cables
Keep your device in an active holder and you will always have a freshly charged battery! The charging connects automatically when you put the device in the holder. This holder features a straight cord for connection inside the vehicle´s dashboard, providing 2A charging. 12/24V. The product is E-approved. Connect the power cable with a 2 A fuse. Professional installation recommended. Charging specifications: - Input voltage: DC/10-30V - Charging voltage: DC/4.75-5.3V - Output current(Typ): 2.0A - Input & output protection: Input polarity reversal/Output over voltage/Output over current/Output short protection - LED charging indicator: Power input indicator(Green), Ovp/Ocp/Output short(Red) - Operating temperature: 0°C ~ +40°C - Storage temperature: -20°C ~ +80°C - RoHS compliant: ROHS
| Meer informatie | |
| Accessoiremerk | Brodit |
| Amperage | 2 Amp |
| Barcode | 7320289410196 |
| Kabel Connectoren | overig |
| Kleur | zwart |
| lader USB connector | Molex |
| Laders en/of USB kabel | Lader zonder kabel |
| Verpakking | Bulkverpakking |
| Voltage (input) | 12/24V geschikt |
| Voltage (output) | 4.75 - 5.25V |
